ThermoBrite System

The ThermoBrite System is an easy, safe programmable temperature controlled slide processing system for in-situ denaturation/hybridization procedures.


View Ordering Information

Description


The ThermoBrite System is a programmable, open system that automates the denaturation and hybridization steps in slide-based FISH procedures and provides walk-away convenience for laboratory personnel. The low cost unit accepts a wide range of sample types, is easy to use, and reduces hands-on time by more than 50% while ensuring overall precision and accuracy in all slide-based assays.

User Programmable Settings

  • 40 user defined protocols and 3 operating modes
  • Easy to read backlit display
  • Numeric keypad allows for easy programming
  • Can be used as a fixed temperature slide warmer

Easy To Use

  • Eliminates manual steps and reduces hands-on time during FISH procedures
  • Slides do not need to be fully loaded to maintain temperature accuracy
  • Slide guide keeps slides in place and allows for one hand removal
  • Humidity Control Cards inside the lid maintain a humid environment

More Stringent Temperature Control

  • Rapid temperature ramp-up and accuracy of ± 1°C
  • Temperature uniformity across all slide positions
  • Heats slide to temperatures ideal for FISH procedures

System Details

The ThermoBrite System holds up to 12 slides. The lid seals tightly when closed providing optimal chamber humidity. The system maintains uniform temperature across all slide positions. Slides can be easily added or removed with one hand. The numeric keypad allows for easy programming with 40 user programmable settings and 3 modes of operation: Denaturation/ Hybridization, Hybridization, and Fixed Temperature.



specifications

ThermoBrite System Technical Specifications
Dimensions Height 146mm (5 5/16 inches)
Width 228 mm (8 5/16 inches)
Depth 451 mm (17 3/4 inches)
Weight 8.5 kg (18.7 lbs)
Capacity 12 slides
Processing Time Programmable 0 to 100 hours
Continuous mode
Power 120 VAC at 3A
240 VAC at 1.6A
Temperature Control Programmable 30-99°C
Ambient Operating Temperature 5-40°C (41-104°F)
Ambient Operating Humidity 20-80% relative
