CE Marked

For In Vitro Diagnostic Use

The Vysis CLL FISH Probe Kit is intended to detect deletion of the LSI TP53, LSI ATM, and LSI D13S319 probe targets and gain of the D12Z3 sequence in peripheral blood specimens from patients with B-cell chronic lymphocytic leukemia (CLL).

The Vysis CLL FISH Probe Kit uses FISH DNA probe technology to determine deletion status of probe targets for locus-specific identifier (LSI) TP53 (containing tumor protein p53 gene, located on chromosome 17p), LSI ATM (containing ataxia telangiectasia mutated gene, located on chromosome 11q), and LSI D13S319 (containing marker D13S319, located on chromosome 13q), as well as determining trisomy 12 with CEP12 (D12Z3 alpha satellite, located on chromosome 12). The Vysis CLL FISH Probe Kit includes LSI 13q34 (containing lysosomal-associated membrane protein 1 gene, located on chromosome 13q) as a control probe.

Explanation of the Test

Chronic lymphocytic leukemia (CLL) is the most common form of adult leukemia in the developed world. Approximately 1 in 202 men and women will be diagnosed with CLL during their lifetime. The median age at diagnosis is approximately 70 years of age. Incidence rates are higher for males (6.44 per 100,000 population) than females (3.51 per 100,000 population). Leukemia incidence is highest among non-Hispanic whites (13.6 per 100,000 population); incidence is lowest among Asian and Pacific Islander populations (7.4 per 100,000 population) and American Indian and Alaska Native populations (7.3 per 100,000 population).

Probe Targets Information

The tumor suppressor protein, p53, has been shown to play a critical role in oncogenesis and response to chemotherapy in a variety of human cancers. In humans, the TP53 gene is found on the short arm of chromosome 17 (17p13) and is reported to be suppressed or mutated in a large number of human cancers. Deletions of the 17p region resulting in abnormalities of the tumor suppressor protein p53 have been identified as one of the poorest prognostic factors for CLL as it is predictive of short time to disease progression, short response duration, lack of response to therapy and short overall survival (OS).

The 17p deletion is more frequently observed in treated patients than in previously untreated patients, increasing in frequency during the course of the disease with up to 50% of patients with relapsed or refractory disease having the deletion. Approximately 8 to 12% of patients with CLL in the first line treatment carry del 17p.6 It is widely accepted that treatment outcomes in patients with del 17p are poor.

Once patients fail purine analog based chemoimmunotherapy, subsequent therapies provide shorter progression-free survival (PFS). 8 The outcome to treatment is strongly impacted by several molecular biologic features and several nonrandom cytogenetic alterations and oncogenes. In particular, an ultra-high risk group of CLL patients has been defined who have deletion of the short arm of chromosome 17 (del17p) with a median life expectancy of less than 2 to 3 years.

Patient Impact

Currently, most patients diagnosed with CLL have early stage-disease (Rai stage 0 or 1). Patients with early-stage CLL are a heterogeneous group; approximately 30% to 50% are at high risk of accelerated disease progression, and the remainder may live for decades and possibly never require therapy. Recent insights into the biological characteristics of leukemic B cells have led to the discovery of new prognostic tools (immunoglobulin variable-region heavy chain gene mutation status, cytogenetic abnormalities assessed by fluorescence in situ hybridization [FISH], and Z-chain-associated protein kinase-70 protein expression) that can contribute to the identification of patients with early-stage disease who are at high risk for early disease progression.

Routine karyotype analysis only detects chromosomal aberrations associated with CLL in 40% to 50% of the cases. Use of FISH and other technologies have detected genomic abnormalities in over 80% of cases of CLL. The common genomic aberrations seen are trisomy 12 and deletions of 13q, 17p, and 11q.

Several published studies suggest that some of these chromosomal abnormalities may be correlated with various disease parameters.

Intended Use

The Vysis CLL FISH Probe Kit is intended to detect deletion of the LSI TP53, LSI ATM, and LSI D13S319 probe targets and gain of the D12Z3 sequence in peripheral blood specimens from patients with B-cell chronic lymphocytic leukemia (CLL). The assay may be used to dichotomize CLL (the 13q-, +12, or normal genotype group versus the 11q- or 17p- group) and may be used as an aid in determining disease prognosis in combination with additional biomarkers, morphology, and other clinical information.

The test is for prescription use only.

Indications and Limitations Of Use

Limitations of the Procedure

For in vitro diagnostic use only.

  1. The Vysis CLL FISH Probe Kit is intended to be used in combination with additional biomarkers, morphology, and other clinical information.
  2. Other signal patterns may occur, and metaphase analysis may be helpful in characterization of such patterns.
  3. If a specimen has a low level abnormal FISH pattern, use of the appropriate single pass filter(s) to confirm the pattern is recommended. Failure to follow this recommendation may result in inaccurate identification of signal patterns.

Clinical Utility


The traditional Rai and Binet clinical CLL staging systems are based on disease burden and have been useful for assigning patients to groups having similar survival times. These systems, however, are not effective in predicting survival in early-stage disease when most CLL cases are diagnosed. This has led to development of newer molecular markers in an attempt to differentiate those patients who are prone to rapid progression from those who have indolent disease.

In a pivotal study conducted by Döhner et al, titled "Genomic Aberrations and Survival in Chronic Lymphocytic Leukemia," genomic alterations as determined by FISH were found to be predictive for disease progression and overall survival. Multiple studies support the conclusion of Döhner et al that loss of 17p and of 11q markers predicts reduced survival times as compared to other Döhner groups as determined by FISH aberrations. Such studies have led to the inclusion of FISH testing in the National Comprehensive Cancer Network (NCCN) practice guidelines as a means to determine CLL prognosis.

In a 2006 prospective study of 151 patients by Shanafelt et al utilizing Vysis FISH probes, a correlation was established between overall survival and FISH risk category for CLL at diagnosis. Patients were divided into two prognostic groups. They were assigned to the good/intermediate FISH prognosis group if there were no chromosomal aberrations or if only 13q- and/or +12 aberrations were present. If a chromosomal aberration of 17p- or 11q- was present, the patient was placed in the poor FISH prognosis group. Poor vs. good/intermediate FISH (P=0.004), age at diagnosis(P=0.0006), and Rai stage (P=0.0026) were each significantly associated with overall survival from diagnosis in univariate analysis. When all factors were included in multivariable Cox regression model, each of three factors still remained significant: poor vs. good/intermediate FISH (P=0.00022), age at diagnosis(P=0.000024), and Rai stage (P=0.00012). The clinical utility of the Vysis CLL FISH Probe Kit has been established primarily from its high concordance with the assay employed in the publication by Shanafelt et al (see method concordance in the package insert). Also, as noted in the Shanafelt study, all patients with the 17p- abnormality had between 24-94% of cells with this abnormality. Therefore, the effect of 17p- at very low levels could not be determined. In a recent publication on untreated 17p- CLL patients, Tam et al reported a 3-year overall survival of 92% for patients with <25% 17p-deleted nuclei, vs. 54% for patients with ≥25% 17p-deleted nuclei (P=0.007).

The National Comprehensive Cancer Network (NCCN) Practice Guidelines™ for Non Hodgkins Lymphoma (v.3.2016) which are the consensus recommendations of leading US oncology experts, states FISH (including abnormalities tested for by this kit) is informative for both prognosis and therapy determination. The guidelines recommend use of FISH at the time of diagnosis as well as re-evaluation by FISH at the time of relapse to direct treatment options (including abnormalities tested for by this kit).
